Specification Parameters

Battery Nominal Voltage:51.2VVdc

Battery Nominal Capacity:184Ah

Battery Nominal Power:9.42kWh

0utput Power:5600W

Output Voltage:230Vac+5%

Output Frequency:50Hz/60Hz

Mains Supply 0utput Voltage:(170Vac-280Vac)±2%@UPS Mode;

(90Vac-280Vac)±2%@APL Generator Mode

Mains Supply Charge Current:DC 60A MAX

Loaded Motor Energy:3HP

PV Rated Operating Voltage:300Vdc

PV Input Voltage：100Vdc~500Vdc

Max PV Input Power:6000W

Max PV Input Current:22A

PV Charge Current:DC 100A MAX

Hybrid Charge Current:DC 100A MAX

Cycle Lifetime:6000time+

Product Dimension:650*300*686mm

Net Weight: 95Kg
